Using things weirdly – Part 3: Moving from State to Hybrid-ish Source Control with Microsoft SSDT and Redgate SQL Change Automation

“It works on MY machine”
Everyone

Some time back I blogged “which database source control model works well for you” and it has come in SO handy when explaining the different models to people – but the one question I get asked not infrequently, is:

Is there any way that I can use Redgate SQL Change Automation with Visual Studio based SSDT?

It’s always a really difficult question to answer because fundamentally SQL Source Control (Redgate’s state based tool) and SSDT (Microsoft’s state based tool) functionally seek to do the same thing, making them competitors. However there are, on the odd occasion, good reasons as to why I am asked the question and one of those same scenarios came up today:

  • Our developers work in Visual Studio and have already been using SSDT for a long time, it works for them, we just want to extend it with Migrations to handle complex changes.

So the option here is, leave it as it is, or try to work with both. Not always going to be my first choice but it got me thinking.

Starting from a memory

A few months ago, when life was “normal” and I was working in my office with *gulp* PEOPLE, I tried to make this scenario work by simply linking SQL Change Automation to the project folder created by SSDT but unfortunately it was riddled with problems. The SSDT importer and repo look like this:

And if you point SQL Change Automation at the local repo with this in it will correctly tell you:

Now of course this wasn’t unexpected. It’s not designed to work this way, is it? No. But way back then I did figure out, shrewdly, that if I used SQL Source Control to carry out an initial commit just to a working folder, it would generate a RedGate.ssc and RedGateDatabaseInfo.xml file and you can copy them into the SSDT repo to trick SQL Change Automation into thinking that it’s a SQL Source Control repo… unfortunately this trick no longer works. Sad.

sad a christmas story GIF

Add a hop and a step

But what got me thinking today was the context with which the question was asked. It was more about separation of duties. Once the developers have effectively done their job and delivered the change into the repo, their job was effectively done! “That’s how it should look moving forwards. What’s next?” – and then I had an idea.

Given that SSDT allows you to push and pull the code and apply it to your own database, what is stopping us from using SQL Change Automation to pick up on the changes against the database we sync our changes to from our SSDT project?

Genius. Evil genius.

So I created a new Database to simulate having another developer on my instance and gave it to Peter Parker:

You can then do a schema compare to another DB from your project, effectively PULL down changes from the remote to your local repository, and then sync them back up to your local development DB; this is how Devs stay up to date with each other but could, in this methodology, be how DBAs or senior developers pull down the changes to their local DB, where they test the new state, and then generate a new migration from it.

So I made a change on my dev database and captured it in the project right click on the project name > schema compare > dev db compare to project > update) and then committed and pushed:

and sure enough my repository was updated:

But then I simulated pulling down the change and applying it to Peter Parker’s DB (again using Schema Compare) and then I created a SQL Change Automation project in VS, in the same solution but pointing the project to a migrations folder in the repo:

Yes I accidentally called the project Database1 don’t remind me I’m embarrassed enough!

Then I added my baseline database:

It created the baseline and the project immediately with no issues and picked up on the changes I had made using SSDT:

and I was able to commit my project and changes into my repository in Azure DevOps:

It was just that easy! Now what this means for the development process is that developers _could_ feasibly work with SSDT, as they are comfortable with it, and then more senior members of the team can generate migration scripts from there, building the database from scratch and deploying in a reliable, repeatable fashion.

Just to prove to you my build even ran green from this:

So in summary what this gives us is the ability to adapt a regular SSDT workflow, one that developers are comfortable with and which has been in the team for months or years, add in the knowledge of DBAs or team leads, a greater separation of duties for high risk schema changes, and the control and flexibility (and peace of mind) that comes with a migrations based deployment process.

Nice.

The fine print

I’m sure by now you’ve realized something: this is not, nor will it ever (I believe) be a supported workflow. If you implement the above in a production sense for something other than just testing then it’s not something you’ll be able to get help with from one of the Redgate engineers if you need to troubleshoot.

Also, if you’re going to introduce a sequence of changes like this to achieve the hybrid model, it does make more sense that you implement SQL Source Control for the state side (given that it’s right there in the SQL Toolbelt with SQL Change Automation anyway).

But IS IT POSSIBLE to achieve a similar, Visual Studio based* hybrid workflow with SSDT and SQL Change Automation by using a database to ‘hop’ the changes across?

Yes, it certainly looks that way!

*If you’re planning on using SSDT in Azure Data Studio too then this workflow could also work for you, SQL Change Automation is present in SSMS and VS so it’s really up to you!

SQL Change Automation and GitLab CI/CD (a.k.a. Oh this is fun on Windows)

“You never know what you can do until you try, and very few try unless they have to.”
C.S. Lewis

Well I don’t have to, but many of the people I speak to on a daily basis are moving into GitLab, so it’s about time I tried it! You can find here testament to the mistakes I make as I try to set up a full end-to-end database change management process with SQL Change Automation and GitLab.

Will it all work perfectly? I don’t doubt that everything will fall over at some point, but let’s see how we get on all the same, and hopefully if you’re setting up this same pipeline, you’ll be able to avoid the errors and failings I inevitably cause! So here we go!

ready come on GIF

Let’s set up a GitLab Project (and rename the default branch)

Naturally, I didn’t have a GitLab account, so I had to set one up. I’m assuming that if you’re using it already or you’ve just started using it you’re taking advantage of the more business features but I’ve just stuck with the good ol’ free account for now! It was remarkably simple, sign up, email address, confirm and here we are:

Ok there is something very cool I like about setting up a new project, can you tell what it is?

You can completely set up a new blank project but they have templates, you can import projects OR, and I love this, you can setup a full CI/CD pipeline from another repo! Having done this before in Azure DevOps it was not easy, let me tell you. It really seems like Azure DevOps hates you for setting up CI/CD from an external repo, even though it has plenty of helpful ways of doing so!

So I initialized my repository with a README and updated it:

Don’t ever say I’m not descriptive enough!

The first thing I did was a renamed my default branch to ‘trunk’ by going to branches, creating the new branch and then in Settings > Repository changing it to the default and then swapping out the protected status with the outdated master:

Then finally delete the old default in Repository > Branches:

Excellent. Now it’s time to clone trunk onto my machine as we will need the local repository to put our change automation project in!

I created a folder called GitLab test and cloned the mostly empty repository into it:

Simple!

Create a new SQL Change Automation project and push it to trunk

In SSMS I opened up the most recent version of SQL Change Automation an created a new project called “DoggosAreCoolDB” using a copy of a Dev database I had lying around from a previous demonstration (BlogsDotRedgate):

Then I created my baseline as a migration script against the up-stream copy, BlogsDotRedgate_Integration, because who has access to Prod for this? Am I right? *cough & shifty eyes* not me!

I successfully generated my baseline and a change script (I added a column to a table, nice and simple) and then committed them to my local repo, and pushed! Forget branching, today isn’t about that, we’re just PUSHING TO TRUNK, WOO-HOO!

Setting up the CI/CD Pipeline

Now that we have our project and migrations in GitLab we can build out a pipeline! So first stop I went straight to CI/CD > Pipelines and was presented and I hit “Get Started”:

They immediately throw you into a Quick Start “Help” style guide which is immediately a little un-intuitive but surprisingly helpful if you read the whole thing. Effectively we need a YAML file called .gitlab-ci.yml that will store our pipeline as code telling it how and where to build, and we need a runner to actually fire up and execute these steps.

In my experience with some other CI/CD tools, it’s been advantageous to actually create the Runner / Agent first on the machines you’re going to be using, so as I just have my laptop to do this on, I will set one up on there! I found the full documentation for a Windows Runner here, and followed it just so I would have it available.

The GitLab Runner was up and running in my services but I’ll be darned if I can see them anywhere in GitLab…

confused britney spears GIF

Aha! So it turns out after a bit of digging that you need to register the runner specifically using the CI/CD section on the project settings, that was probably my bad for not reading the documentation thoroughly but my counter-argument… who actually does? So I issued the register command, applied tags and a description and chose my runner type, I chose shell because I need to be able to run PowerShell on the machine (I’ll need the SQL Change Automation PowerShell components available on the machine where the Build and Deployment are happening of course):

I’ve got the runner on the machine, I’m using an instance of SQL Server to build against, now I just need the YAML file (fortunately GitLab has full documentation for how to structure this as well!)

So I can build my project I’m going to need to know where the repo is cloned to during the process (i.e. to find the .sqlproj file) so by taking a look I managed to find a list of environment variables that can be used in the YAML file, just to be sure though, I created and committed the most basic YAML file that would just echo back the location of the cloned files:

stages:
  - DatabaseBuild

Build:
  stage: DatabaseBuild
  tags:
   - sql
  script:
   - echo $env:CI_PROJECT_DIR

After this let me know the environment variable worked correctly and the build pipeline was being fired up correctly on my private runner, I tried something a little more ambitious, building the .sqlproj file using the cmdlet reference from the SQL Change Automation documentation for help:

stages:
  - DatabaseBuild

Build:
  stage: DatabaseBuild
  tags:
   - sql
  script:
   - $projectPath = $env:CI_PROJECT_DIR
   - $project = "$projectPath\DoggosAreCoolDB\DoggosAreCoolDB.sqlproj"
   - $validatedProject = $project | Invoke-DatabaseBuild -TemporaryDatabaseServer "Data Source=PSE-LT-CHRISU\"

and we successfully built a database!

All that’s left to do now is 2 things:

  1. Create a NuGet package as part of the CI build
  2. Release the database changes to the target DB

I’m still using the same machine for the release portion too, so naturally I can use the same runner for this, if you have other servers you’re deploying to you will of course need additional runners.

We can very easily extend what we already have in our YAML file by just telling the process to create and export a new build artifact – I’m going to name it the same as everything else, and then append the BuildId to the end of the file so we always get something unique:

stages:
  - DatabaseBuild

Build:
  stage: DatabaseBuild
  tags:
   - sql
  script:
   - $projectPath = $env:CI_PROJECT_DIR
   - $project = "$projectPath\DoggosAreCoolDB\DoggosAreCoolDB.sqlproj"
   - $validatedProject = $project | Invoke-DatabaseBuild -TemporaryDatabaseServer "Data Source=PSE-LT-CHRISU\"
   - $buildArtifact = $validatedProject | New-DatabaseBuildArtifact -PackageId DoggosAreCool.Database -PackageVersion 1.$env:CI_JOB_ID
   - $buildArtifact | Export-DatabaseBuildArtifact -Path "$env:CI_PROJECT_DIR\Export"
  artifacts:
    paths:
     - $env:CI_PROJECT_DIR\Export\DoggosAreCool.Database.1.$env:CI_JOB_ID.nupkg
    expire_in: 1 week

You’ll notice how I’m exporting the NuGet package to the project directory and then uploading it, this is so that we’ll have access to it to release but also so that we can use the artifacts argument in our YAML to upload the file and make it a downloadable package through the GitLab interface (if you go to that SPECIFIC job):

Whilst we’re on a roll here (and things haven’t gone wrong for a while) I’m going to add 2 additional stages ALL AT ONCE to both “Create a Database Release Artifact” and “Deploy from a Database Release Artifact” using, once again, the SQL Change Automation PowerShell cmdlets.

Woo-Hoo! I’m invincible!

I broke it.

Can you see what I did wrong? The error is:

New-DatabaseReleaseArtifact : The specified value for the Source parameter is neither a valid
41database connection string nor a path to an existing NuGet package file or scripts folder:
42'CI_PROJECT_DIR\Export\DoggosAreCool.Database.1.725147351.nupkg'

So 2 fun things. 1 – I forgot to highlight there was an environment variable at one point, so it was just looking for the name of the variable in the path and 2) it keeps erroring out saying my NuGet file isn’t a NuGet file, weird right?

On further inspection it is yet another mistake I made. I’m using the job ID to name the NuGet package, which means when it tries to find the file it’s 2 steps ahead because each stage is counted as a different job! Duh!

sylvester stallone facepalm GIF

A few quick changes should hopefully sort this out! I’m going to put the instance of the pipeline ID in ($env:CI_PIPELINE_ID) and see if that makes a difference!

Wait. Did it just say the pipeline ran? SUCESSFULLY? That’s exactly what it said! We can verify that this actually happened as well by checking the DatabaseDeploymentResources folder for the Release Artifact to Integration:

And everything is there! Note you won’t have a changes.html report just yet because this is the first time we’ve successfully deployed to Integration, however if we run 1 more change through (I’ll add a stored procedure):

Boom.

Prince Harry Mic Drop GIF

Now of course we can add additional stages to this, for manual intervention or to promote to other environments, but I’m going to call it a win here and retire (until the next post) gracefully. I’m sure you’re all wondering what my final YAML file looked like too – well (counterintuitively) I’ve popped it all into GitHub for you and pasted it below. Enjoy!

stages:
  - DatabaseBuild
  - CreateRelease
  - DeployToIntegration

Build:
  stage: DatabaseBuild
  tags:
   - sql
  script:
   - $projectPath = $env:CI_PROJECT_DIR
   - $project = "$projectPath\DoggosAreCoolDB\DoggosAreCoolDB.sqlproj"
   - echo "Building project $project"
   - $validatedProject = $project | Invoke-DatabaseBuild -TemporaryDatabaseServer "Data Source=PSE-LT-CHRISU\"
   - $buildArtifact = $validatedProject | New-DatabaseBuildArtifact -PackageId DoggosAreCool.Database -PackageVersion 1.$env:CI_PIPELINE_ID
   - echo "Exporting artifact to $env:CI_PROJECT_DIR\Export"
   - $buildArtifact | Export-DatabaseBuildArtifact -Path "$env:CI_PROJECT_DIR\Export"
  artifacts:
    paths:
     - $env:CI_PROJECT_DIR\Export\DoggosAreCool.Database.1.$env:CI_PIPELINE_ID.nupkg
    expire_in: 1 week

CreateRelease:
  stage: CreateRelease
  tags:
   - sql
  script:
   - $integrationDB = New-DatabaseConnection -ServerInstance "PSE-LT-CHRISU\" -Database "BlogsDotRedgate_Integration"
   - $buildArtifact = "$env:CI_PROJECT_DIR\Export\DoggosAreCool.Database.1.$env:CI_PIPELINE_ID.nupkg"
   - echo "Creating Release Artifact for DoggosAreCuteDB - check C:\DatabaseDeploymentResources\DoggosAreCuteInc\ReleaseArtifacts\$env:CI_PIPELINE_ID\Integration for more information"
   - $releaseArtifact = New-DatabaseReleaseArtifact -Source $buildArtifact -Target $integrationDB
   - $releaseArtifact | Export-DatabaseReleaseArtifact -Path "C:\DatabaseDeploymentResources\DoggosAreCuteInc\ReleaseArtifacts\$env:CI_PIPELINE_ID\Integration" -Format Folder

Integration:
  stage: DeployToIntegration
  tags:
   - sql
  script:
   - $integrationDB = New-DatabaseConnection -ServerInstance "PSE-LT-CHRISU\" -Database "BlogsDotRedgate_Integration"
   - echo "Deploying changes to Integration"
   - Import-DatabaseReleaseArtifact -Path "C:\DatabaseDeploymentResources\DoggosAreCuteInc\ReleaseArtifacts\$env:CI_PIPELINE_ID\Integration" | Use-DatabaseReleaseArtifact -DeployTo $integrationDB
