3 methods for seeding test data during CI builds with Flyway

“It is a capital mistake to theorize before one has data. Insensibly one begins to twist facts to suit theories, instead of theories to suit facts.
Sir Arthur Conan Doyle, Sherlock Holmes

Can you tell I’m loving Flyway at the moment? Well I am. It’s JUST SO GOOD! Honestly there are so many things you can do with it! Don’t know what I’m talking about? Check out my posts on xRDBMS DevOps with Flyway and tSQLt unit tests with Flyway and you’ll see what I mean!

As a result of the above posts though I was asked a question that I had to think about for a little bit before having the best possible answer, how can we seed some testing data INTO the build database so that we can run some meaningful tests against it?

This makes perfect sense to me, but there’s also a few different ways to do this – so let’s go fly(way)!

flying i believe i can fly GIF

1 – Test Data Migration Scripts

In my previous posts on Flyway (above) I talked about having an entirely separate build folder present within the repository, and a folder of test migrations alongside our schema migrations – I called these the Build_Config folder, (containing the build configuration file) and the Test_Migrations folder (unsurprisingly containing testing migrations) in the _Migrations location:

I was using the same build config for 2 purposes; 1) to build the schema migrations from the base version, by passing it the Schema_Migrations location dynamically and 2) then building the tSQLt framework and testing objects by passing it the Test_Migrations location dynamically.

This actually worked surprisingly well, but even beyond this – the same method can be repurposed, or added to, by augmenting your testing scripts and adding a data insertion task (as an additional script or group of scripts). In my folder, I can simply add a migration like this:

Because of course I like dogs.

lana del rey yes GIF

and once pushed to the repository and the build has run we should be able to verify our testing data is present:

A bonus win for this step of course, is that where Devs have their own Flyway config files locally for their development databases they could also overwrite this behavior and point the testing and/or data scripts at their own database so they have some seed data to work with too!

2 – Add a data generation step to the pipeline

There are SO MANY technologies out on the inter-webs for generating data. SO MANY. Many of them also have a command line or PowerShell module that we can use to easily invoke them against a target, especially if that target is going to be persistent like my Flyway Azure SQL Build DBs!

Because I have access to it and because I’m using essentially SQL Server DBs, I could easily use Redgate SQL Data Generator – but to get the data you need you could use anything from DBATools Data Generation (also SQL Server) to FillDB for MySQL (which looks awesome and you could easily use this for Step 1 above too!)

There are numerous ways to invoke tools and applications and fortunately good CI/CD tools like Azure DevOps offer multiple ways to, for instance, run PowerShell or CLI steps from within the pipeline – so we could easily invoke SQL Data Generator on a VM or physical machine we have an Azure DevOps agent on – but this thinking also opens up the possibility of using something like Chocolatey to dynamically install the software on the Azure DevOps hosted pool VM during build (for the Redgate tools at the moment I suppose you’d need a Windows VM).

sassy pants chocolate GIF

I will be writing a future blog post about this step because it sounds _very_ interesting, but I’m not sure yet what can be done specifically using Chocolatey or if I’ll have to look elsewhere, although I have read this post in the past (thanks Paul!) detailing limitations and a great workaround using Azure DevOps, so it’s likely that’ll be my first port of call!

Just to give you an idea of end result with SQL Data Generator specifically though:

3 – Use existing data, don’t generate

Ok this one is going to be controversial already, I can tell! Let’s all stay calm!

happy chill GIF

The best data to be tested is our data. What we have in Production is what will have these changes deployed to it… eventually! So shouldn’t we just test against that? Well. Maybe, maybe not depending on what is in there.

There’s a few methods to achieve this – my personal favorite would be to use a SQL Clone, spin that up on a build VM rather than using an Azure SQL DB, and we can have all the data in an instant. Of course if we hold any sensitive PII/PHI then we should ensure that is protected first!

Of course there are lots of other options, like restoring a backup or spinning up a container etc. and these can all just be a stage in the YAML file before invoking Flyway but the point is, if we use an existing copy of our Prod database from some source or another, it will have 2 things we really care about:

  1. Data. Ready to go, ready to test, ready to give us the best possible insight into our changes.
  2. The flyway_schema_history table. Instead of running EVERY migration we’ve ever written, which could take a while for a large team, we run only the latest migrations to check that they would deploy happily to the Production target.

To get this stage to work though, you would need to do a couple of things differently:

  1. The build DB would have to be created from the clone/backup/other every time instead of simply cleaning the schema down.
  2. You would need to remove the Flyway Clean step from the pipeline in my previous post, because it would otherwise drop all the tables (and then we wouldn’t have any data!)
  3. By extension, this also makes the callback to remove the tSQLt objects void, so you can remove that too.

Conclusion

There are a lot of different ways to generate data, you can generate completely synthetic data, you can mask data or use Prod data, it’s up to you! Ultimately it will just for another part of your pipeline – just be careful of ordering! You don’t want to try generating data into a table that hasn’t been built yet.

Respect your YAML file and you’ll get schema, data and unit tests and this will lead to one thing. Greater insight, earlier.

thumbs up GIF

xRDBMS Database Continuous Integration with Flyway, Azure DevOps and Docker… the simple way.

“Some people try to make everything complicated, be the person who tries to make everything simple.”
Dave Waters

Simplicity is in my blood. That’s not to say I am ‘simple’ in the sense I cannot grasp more than the most basic concepts, but more that I am likely to grasp more complex problems and solutions when they are phrased in simple ways.

This stems from my love of teaching others (on the rare occasion it falls to me to do so), where I find the moment that everything just ‘clicks’ and the realization comes over them to be possibly one of the most satisfying moments one can enjoy in life.

shocked star trek GIF

Now recently I’ve been enjoying getting my head around Flyway – an open source JDBC based migrations tool that brings the power of schema versioning and deployments together with the agility that developers need to focus on innovation in Development. There’s something about Flyway that just… ‘clicks’.

It doesn’t really matter what relational database you’re using; MySQL, IBM DB2, even SAP HANA! You can achieve at least the core tenants of database DevOps with this neat and simple little command line tool – there’s not even an installer, you just have to unzip!

Now I’ve had a lot of fun working with Flyway so far and, thanks to a few people (Kendra, Julia – i’m looking at you both!) I have been able to wrap my head around it to, I would say, a fair standard. Caveat on that – being a pure SQL person please don’t ask me about Java based migrations, I’m not quite there yet!! But there is one thing that I kept asking myself:

“When I’m talking to colleagues and customers about Database DevOps, I’m always talking about the benefits of continuous integration; building the database from scratch to ensure that everything builds and validates…” etc. etc. so why haven’t I really come across this with Flyway yet?

think tom hanks GIF by The Late Show With Stephen Colbert

Probably for a few reasons. You can include Flyway as a plugin in your Maven and Gradle configurations, so people writing java projects already get that benefit. It can easily form part Flyway itself by virtue is simply small incremental scripts and developers can go backwards and forwards however and as many times as they like with the Flyway Migrate, Undo and Clean commands, so is there really a need for a build? And most importantly, Flyway’s API just allows you to build it in. So naturally you’re building WITH the application.

But naturally when you’re putting your code with other people’s code, things have to be tested and verified, and I like to do this in isolation too – especially for databases that are decoupled from the application, or if you have a number of micro-service style databases you’d want to test all in parallel etc. it’s a great way to shift left. So I started asking myself if there was some way I could implement a CI build using Flyway in Azure DevOps, like I would any of the other database tooling I use on a regular basis? Below you’ll find the product of my tinkering, and a whole heap of help from Julia and Kendra, without whom I would still be figuring out what Baseline does!

Option 1) The simplest option – cmdline

Flyway can be called via the command line and it doesn’t get more simple than that.

You can pass any number of arguments and switches to Flyways command line, including specifying what config files it’s going to be using – which means that all you have to do, is unzip the Flyway components on a dedicated build server (VM or on-prem) and then, after refreshing the migrations available, invoke the command line using Azure DevOps pipelines (or another CI tool) to run Flyway with the commands against a database on the build server (or somewhere accessible to the build server) and Bingo!

No Idea Build GIF by Rooster Teeth

And that’s all there is to it! You get to verify that all of the migrations up to the very latest in your VCS will run, and even if you don’t have the VERY base version as a baseline migration, you can still start with a copy of the database – you could even use a Clone for that!

But yes, this does require somewhere for Flyway to exist prior to us running with our migrations… wouldn’t it be even easier if we could do it without even having to unzip Flyway first?

Option 2) Also simple, but very cool! Flyway with Docker

Did you know that Flyway has it’s own docker image? No? Well it does!* Not only that but we can map our own version controlled Migration scripts and Config files to the container so that, if it can point at a database, you sure as heck know it’s going to migrate to it!

*Not sure what the heck all of this Docker/Container stuff is? You’re not alone! Check out this great video on all things containers from The Simple Engineer!

This was the method I tried, and it all started with putting a migration into Version Control. Much like I did for my post on using SQL Change Automation with Azure SQL DB – I set up a repo in Azure DevOps, cloned it down to my local machine and I added a folder for the migrations:

Into this I proceeded to add my base script for creating the DMDatabase (the database I use for EVERYTHING, for which you can find the scripts here):

Once I had included my migration I did the standard

Git add .
Git commit -m "Here is some code"
Git push

and I had a basis from which to work.

Next step then was making sure I had a database to work with. Now the beauty of Flyway means that it can easily support 20+ RDBMS’ so I was like a child at a candy store! I didn’t know what to pick!

For pure ease and again, simplicity, I went for good ol’ SQL Server – or to be precise, I created an Azure SQL Database (at the basic tier too so it’s only costing £3 per month!):

Now here’s where it gets customizable. You don’t NEED to actually even pass in a whole config file to this process. Because the Flyway container is going to spin up everything that would come with an install of Flyway, you can pass it switches to override the default behavior specified in the config file. You can adapt this either by hard-coding strings or by using Environment Variables alongside the native switches – this means you could pass in everything you might need securely through Azure Pipeline’s own methods.

I, on the other hand, was incredibly lazy and decided to use the same config file I use for my Dev environment, but I swapped out the JDBC connection to instead be my Build database:

I think saved this new conf file in my local repo under a folder named Build Configuration – in case I want to add any logic later on to include in the build (like the tSQLt framework and tests! Hint Hint!)

This means that I would only need to specify 2 things as variables, the location of my SQL migrations, and the config file. So the next challenge was getting the docker container up and running, which fortunately it’s very easy to do in Azure Pipelines, here was the entirety of the YAML to run Flyway in a container (and do nothing with it yet):

trigger:
- master

pool:
  vmImage: 'ubuntu-latest'

steps:
- task: DockerInstaller@0
  inputs:
    dockerVersion: '17.09.0-ce'
  displayName: 'Install Docker'

- task: Bash@3
  inputs:
    targettype: 'inline'
    script: docker run flyway/flyway -v
  displayName: 'Run Flyway'

So, on any changes to the main branch we’ll be spinning up a Linux VM, grabbing Docker and firing up the Flyway container. That’s it. Simple.

So now I just have to pass in my config file, which is already in my ‘build config’ folder, and my migrations which are in my VCS root. To do this it was a case of mapping where Azure DevOps stores the files from Git during the build to the containers own mount location in which it expects to find the relevant conf and sql files. Fortunately Flyway and Docker have some pretty snazzy and super clear documentation on this – so it was a case of using:

-v [my sql files in vcs]:/flyway/sql

as part of the run – though I had to ensure I also cleaned the build environment first, otherwise it would just be like deploying to a regular database, and we want to make sure we can build from the ground up every single time! This lead to me having the following environment variables:

As, rather helpfully, all of our files from Git are copied to the working directory during the build and we can use the environment variable $(Build.Repository.LocalPath) to grab them! This lead to me updating my YAML to actually do some Flyway running when we spin up the container!

trigger:
- master

pool:
  vmImage: 'ubuntu-latest'

steps:
- task: DockerInstaller@0
  inputs:
    dockerVersion: '17.09.0-ce'
  displayName: 'Install Docker'

- task: Bash@3
  inputs:
    targettype: 'inline'
    script: docker run -v $(FLYWAY_LOCATIONS):/flyway/sql -v $(FLYWAY_CONFIG_FILES):/flyway/conf flyway/flyway clean -enterprise
  displayName: 'Clean build schema'

- task: Bash@3
  inputs:
    targettype: 'inline'
    script: docker run -v $(FLYWAY_LOCATIONS):/flyway/sql -v $(FLYWAY_CONFIG_FILES):/flyway/conf flyway/flyway migrate -enterprise
  displayName: 'Run flyway for schema'

Effectively, this will spin up the VM in ADO, download and install Docker, fire up the Flyway container and then 1) clean the target schema (my Azure SQL DB in this case) and 2) then migrate all of the migrations scripts in the repo up to the latest version – and this all seemed to work great!*

*Note: I have an enterprise Flyway licenses which enables loads of great features and support, different version comparisons can be found described here.

So now, whenever I add Flyway SQL migrations to my repo as part of a branch, I can create a PR, merge them back into Trunk and trigger an automatic build against my Flyway build DB in Azure SQL:

Conclusion

Getting up and running with Flyway is so very very easy, anyone can do it – it’s part of the beauty of the technology, but it turns out getting the build up and running too, when you’re not just embedding it directly within your application, is just as straightforward and it was a great learning curve for me!

The best part about this though – is that everything above can be achieved using pretty much any relational database management system you would like, either via the command line and a dedicated build server, or via the Docker container at build time. So get building!
